its 1PPS input that is used to perform disciplining. If this estimated error is too large, it could
adversely affect the performance of oscillator disciplining. The available TFOM range is 1
through 15. You may refer to the following for the TFOM to ETE conversions:
Table 3-5:
TFOM to ETE conversion
Reported TFOM Value Estimated Time Error (ETE)
1 <= 1 nsec
2 1 nsec < ETE <= 10 nsec
3 10 nsec < ETE <= 100 nsec
4 100 nsec < ETE <= 1 μsec
5 1 μsec < ETE <= 10 μsec
6 10 μsec < ETE <= 100 μsec
7 100 μsec < ETE <= 1 msec
8 1 msec < ETE <= 10 msec
9 10 msec < ETE <= 100 msec
10 100 msec < ETE <= 1 sec
11 1 sec < ETE <= 10 sec
12 10 sec < ETE <= 100 sec
13 100 sec < ETE <= 1000 sec
14 1000 sec < ETE <= 10000 sec
15 ETE > 10000 sec
Example
TFOM is a value between 1 and 15. TFOM can never exceed the default MaxTFOM value
of 15.
Typically the MaxTFOMrequires no adjustment, but in some instances it may be advisable
to decrease MaxTFOM so that TFOM can potentially exceed it: For example, by lowering
the MaxTFOM to “5” it is now possible for TFOM to be always higher than the MaxTFOM
value:
Assuming the MaxTFOM is set to 5 and the TFOM happens to go to a 6, i.e. TFOM is now
exceeding MaxTFOM. This condition will cause a 1PPS out of specification alarm to be
asserted and the oscillator disciplining will change in order to speed-up the alignment of
the system 1PPS to the selected reference (causing it to take less time getting closer into
alignment with the reference):
This will cause the TFOM to start to decrease faster. Once TFOM no longer exceeds
MaxTFOM because the System 1PPS is now much closer to the reference 1PPS, the dis-
232
CHAPTER 3 SecureSync 2400 User Manual Rev. 2
3.5 Managing the Oscillator
