Orolia SecureSync 2400 User Manual

Table 1-4:
Option cards identification
Function Web UI Name Illustration ID* Inputs Outputs Conn.'s
Time and Frequency Cards
Quad 1PPS
out (TTL)
1PPS Out BNC
18
0 1PPS, TTL
(4x)
BNC
(4x)
Quad 1PPS
out (10 V)
1PPS Out 10V
19
0 1PPS, 10 V
(4x)
BNC
(4x)
Quad 1PPS
out (RS-
485)
1PPS Out, RS-
485
21
0 1PPS, RS-
485 (4x)
Terminal
block, 10-
pin
Quad 1PPS
out (fiber
optic)
1PPS Out, Fiber
2B
0 1PPS, F/O
(4x)
ST Fiber
optic
(4x)
1in/3out
1PPS (TTL
[BNC])
1PPS/Frequency
RS-485
28
1PPS (1x) 1PPS (3x) BNC
(4x)
5MHz out 5MHz Out
08
0 5MHz (3x) BNC (3x)
10 MHz out 10 MHz Out
1C
0 10 MHz (3x) BNC (3x)
1MHz out 1MHz Out
26
0 1MHz (3x) BNC (3x)
Progr.
frequ. out
(Sine
Wave)
Prog Freq Out,
Sine
13
0 progr. clock,
sine (4x)
BNC
(4x)
Progr.
frequ out
(TTL)
Prog Freq Out,
TTL
2F
0 progr. clock,
TTL/sq. (4x)
BNC
(4x)
Prog frequ
out (RS-
485)
Prog Freq Out,
RS-485
30
0 progr. clock,
RS-485 (4x)
Terminal
block, 10-
pin
Square
Wave out
Square Wave
Out, BNC
17
0 square
wave, TTL
(4x)
BNC
(4x)
1PPS in/out
+ frequ. in
1PPS/Frequency
BNC
01
Var. frequ. +
1PPS
1PPS (TTL) BNC (3x)
1PPS in/out
+ frequ. in
1PPS/Frequency
RS-485
03
10 MHz +
1PPS
1PPS Terminal
block, 10-
pin
16
CHAPTER 1 • SecureSync 2400 User Manual Rev. 2
1.5 Option Cards
