Card
ID*
Card Name Name in UI See ...
08 5 MHz output module (3 out-
puts)
5 MHz Out
"Frequency Out [1204-08, -1C, -
26]" on page370
09 T1-1.544 (75 Ω) or E1-2.048
(75 Ω) module
E1/T1 Out BNC
"T1/E1 Out [1204-09, -0A, -4C, -
53]" on page390
0A T1-1.544 (100 Ω) or E1-2.048
(120 Ω) module
E1/T1 Out Ter-
minal
"T1/E1 Out [1204-09, -0A, -4C, -
53]" on page390
0F Alarm module Relay Output
"Alarm Relay Out [1204-0F]" on
page487
10 HaveQuick output module
(TTL)
HAVE QUICK
Out, BNC
"HAVE QUICK Out [1204-10, -1B]"
on page433
11 STANAG output module STANAG Out
"STANAG Out [1204-11, -25]" on
page418
13 Programmable Frequency
Output module (Sine Wave)
Prog Freq Out,
Sine
"Programmable Frequency Out
[1204-13, -2F, -30]" on page373
14 CTCSS, Data Sync/Clock mod-
ule ("Simulcast")
Simulcast
"Simulcast (CTCSS/Data Clock)
[1204-14]" on page381
15 IRIG module, BNC (4 outputs) IRIG Out BNC
"IRIG Out [1204-15, -1E, -22]" on
page397
17 Square Wave (TTL) output
module
Sq Wv Out, BNC
"Programmable Square Wave Out
[1204-17]" on page378
18 Quad 1 PPS output module
(TTL)
1PPS Out BNC
"1PPS Out [1204-18, -19, -21, -2B]"
on page354
19 Quad 1 PPS output module (10
V)
1PPS Out 10V
"1PPS Out [1204-18, -19, -21, -2B]"
on page354
1B HaveQuick output module (RS-
485)
HAVEQUICK
Out, RS-485
"HAVE QUICK Out [1204-10, -1B]"
on page433
1C 10 MHz output module (3 out-
puts)
10 MHz Out
"Frequency Out [1204-08, -1C, -
26]" on page370
1D STANAG input module STANAG In
"STANAG In [1204-1D, -24]" on
page425
1E IRIG module, Fiber Optic (4
outputs)
IRIGOut, Fiber
"IRIG Out [1204-15, -1E, -22]" on
page397
1F NENA Card NENA
"NENA-Compliant Option Card [-
1F]" on page492
21 Quad 1 PPS output module
(RS-485 [terminal block])
1PPS Out, RS-
485
"1PPS Out [1204-18, -19, -21, -2B]"
on page354
22 IRIG module, RS-485 (4 out-
puts)
IRIG Out, RS-
485
"IRIG Out [1204-15, -1E, -22]" on
page397
