Table 5-9:
CTCSS exact (1/10 Hz) tones
Code Tone Freq. Code Tone Freq. Code Tone Freq.
XZ 67.0 1B 107.2 6A 173.8
WZ 69.3 2Z 110.9 6B 179.9
XA 71.9 2A 114.8 7Z 186.2
WA 74.4 2B 118.8 7A 192.8
XB 77.0 3Z 123.0 M1 203.5
WB 79.7 3A 127.3 8Z 206.5
YZ 82.5 3B 131.8 M2 210.7
YA 85.4 4Z 136.5 M3 218.1
YB 88.5 4A 141.3 M4 225.7
ZZ 91.5 4B 146.2 9Z 229.1
ZA 94.8 5Z 151.4 M5 233.6
ZB 97.4 5A 156.7 M6 241.8
1Z 100.0 5B 162.2 M7 250.3
1A 103.5 6Z 167.9 0Z 254.1
Table 5-10:
Data Clock Signals
Output Duty Cycle
9.6 kHz, 18.0 kHz, 64.0 kHz 50% ±2%
17 2/3 Hz 888 µs pulse width
26 2/3 Hz 25% low, 75% high
33 1/3 Hz 208 µs pulse width
Table 5-11:
1PPS Duty Cycle
Output Duty Cycle
1PPS 20% ±5%
