Orolia SecureSync 2400 User Manual

The Status window displays the following settings:
Event Capture: Enables the processing of events on the Event Input port J2. When
set to “Disabled”, no event messages will be queued. When set to “Enabled”, event
messages will be triggered (if a valid Format is selected).
Event Active Edge: Selects the signal edge used for triggering events on Event
Input port J2.
Event Broadcast Input: Status Window
To view the current settings of the Event Broadcast Input, (also referred to as ‘Refer-
ence ’), go to its Status window. For instructions, see: "Viewing Input/Output Con-
figuration Settings" on page334.
The Web UI list entry for this card is: Event Broadcast.
The Status window displays the following settings:
Event Capture: The processing of events on the Event Input port J2. When set to
“Disabled”, no event messages will be queued. When set to “Enabled”, event mes-
sages will be triggered (if a valid Format is selected).
Event Active Edge: The signal edge used for triggering events on Event Input port
J2.
Latest Event Message: The last message sent. This can be cleared with the Clear
button.
Event Broadcast Time Code Formats
The following ASCII-based time code formats are available:
SecureSync 2400 User Manual 511
APPENDIX
