recall recorders, and sequential event loggers found in emergency dispatch centers and
power utilities.
Table 5-28:
Available IRIG output signals
Format Encoding Modulation Carrier Coded Expressions Bit rate
Time Frame
Interval
IRIG-A
IRIG-A A000 DCLS N/A BCD
TOY
, CF and SBS 1000
pps
0.1 sec
IRIG-A A001 DCLS N/A BCD
TOY
, CF 1000
pps
0.1 sec
IRIG-A A002 DCLS N/A BCD
TOY
1000
pps
0.1 sec
IRIG-A A003 DCLS N/A BCD
TOY
, SBS 1000
pps
0.1 sec
IRIG-A A004 DCLS N/A BCD
TOY
, BCD
YEAR
, CF
and SBS
1000
pps
0.1 sec
IRIG-A A005 DCLS N/A BCD
TOY
, BCD
YEAR
, and
CF
1000
pps
0.1 sec
IRIG-A A006 DCLS N/A BCD
TOY
, BCD
YEAR
1000
pps
0.1 sec
IRIG-A A007 DCLS N/A BCD
TOY
, BCD
YEAR
, and
SBS
1000
pps
0.1 sec
IRIG-A A130 AM 10 kHz BCD
TOY
, CF and SBS 1000
pps
0.1 sec
IRIG-A A131 AM 10 kHz BCD
TOY
, CF 1000
pps
0.1 sec
IRIG-A A132 AM 10 kHz BCD
TOY
1000
pps
0.1 sec
IRIG-A A133 AM 10 kHz BCD
TOY
, SBS 1000
pps
0.1 sec
IRIG-A A134 AM 10 kHz BCD
TOY
, BCD
YEAR
, CF
and SBS
1000
pps
0.1 sec
IRIG-A A135 AM 10 kHz BCD
TOY
, BCD
YEAR
, and
CF
1000
pps
0.1 sec
IRIG-A A136 AM 10 kHz BCD
TOY
, BCD
YEAR
1000
pps
0.1 sec
