Bit Switches – 1
SM 57 D0C5/D0C6/D0C4/D0AP FAX UNIT
(D0C5/D0C6
/D0C4/D0AP)
Default setting: 02(H) = 512 KB
System Switch 11 (SP No. 1-101-018)
No Function Comments
0 TTI printing position
0: Superimposed on the page
data
1: Printed before the data
leading edge
Change this bit to 1 if the TTI overprints information that
the customer considers to be important (G3
transmissions).
NOTE: If "1" is selected, it is possible that sent data is
printed on two sheets of paper.
1-2 Not used Do not change these settings.
3 TTI used for broadcasting
0: The TTIs selected for each
Quick/Speed dial are used
1: The same TTI is used for all
destinations
1: The TTI (TTI_1 or TTI_2) which is selected for all
destinations during broadcasting.
4-7 Not used Do not change these settings.
System Switch 12 (SP No. 1-101-019)
No Function Comments
0-7 TTI printing
position in the
main scan
direction
TTI: 08 to 92 (BCD) mm
Input even numbers only.
This setting determines the print start position for the TTI from the left
edge of the paper. If the TTI is moved too far to the right, it may
overwrite the file number which is on the top right of the page. On an A4
page, if the TTI is moved over by more than 50 mm, it may overwrite the
page number.
System Switch 13 - Not used (do not change these settings)
System Switch 14 - Not used (do not change these settings)
System Switch 15 (SP No. 1-101-022)
No Function Comments
0 Not used Do not change the settings.
1 Going into the Energy Saver mode
automatically
0: Enabled
1: Disabled
1: The machine will restart from the Energy Saver
mode quickly because the +5V power supply is active
even in the Energy Saver mode. The LED of the
operation switch is flashing instead of entering Energy
Saver mode.
Use this setting if an external telephone has to be
