Status word G115D (ZSW_G115D)
Bit Meaning Description Signal interconnec‐
tion in the converter
0 1=DI 0 Status of the digital input 0 p2084[0] = r0722.0
1 1=DI 1 Status of the digital input 1 p2084[1] = r0722.1
2 1= DI 2 Status of the digital input 2 p2084[2] = r0722.2
3 1=DI 3 Status of the digital input 3 p2084[3] = r0722.3
4 1= DI 24 Status of the digital input 24 p2084[4] = r0722.24
5 1= DI 25 Status of the digital input 25 p2084[5] = r0722.25
6 Not used
7 Not used
8 1 = Repair switch OFF Repair switch is set to OFF and all
power to the motor is termina‐
ted.
p2084[8] = r8559.12
9 1 = Remote control active Remote control mode is activa‐
ted via the LRC panel.
p2084[9] = r8559.2
10 1 = Manual mode active Local control mode is activated
via the LRC panel.
p2084[10] = r8559.3
11 1 = Sensor bypass activated Stop/low speed sensor bypass is
activated for the conveyor con‐
trol.
p2084[11] = r8559.4
12 1 = Continuous motion activated Continuous motion is activated
via the LRC panel.
p2084[12] = r8559.5
13 1 = Jog left active Motor Jogs to the left. p2084[13] = r8559.6
14 1 = Jog right active Motor Jogs to the right. p2084[14] = r8559.7
15 Not used
