Siemens SINAMICS G115D

DIP switch Value
DIP 2.1 DIP 2.2 DIP 2.3 DIP 2.4
ON ON OFF OFF 0.3 s
OFF OFF ON OFF 0.5 s
ON OFF ON OFF 0.7 s
OFF ON ON OFF 1 s
ON ON ON OFF 2 s
OFF OFF OFF ON 3 s
ON OFF OFF ON 5 s
OFF ON OFF ON 7 s
ON ON OFF ON 10 s
OFF OFF ON ON 20 s
ON OFF ON ON 30 s
OFF ON ON ON 50 s
ON ON ON ON 70 s
Commissioning DIP switches 2.5 ... 2.7: macro selection
DIP switch Value for PROFI‐
NET variant
Value for AS-i
variant
Value for I/O
variant
DIP 2.5 DIP 2.6 DIP 2.7
OFF OFF OFF p0015 * p0015 * p0015 *
ON OFF OFF - Macro 31 Macro 9
OFF ON OFF - Macro 34 Macro 60
ON ON OFF - Macro 66 Macro 61
OFF OFF ON - - Macro 62
ON OFF ON - - Macro 63
OFF ON ON - - Macro 64
* You must carry out quick commissioning in order to set parameter p0015.
For more information about the p0015 macros, see Section "Factory interface setting
(Page82)".
6.4.2 Quick commissioning with a PC (Startdrive)
Overview
You can use a PC installed with Startdrive to perform quick commissioning via a USB or PROFINET
interface. This chapter describes the commissioning via a USB interface.
The screen forms that are shown in this manual show generally valid examples. The number
of setting options available in screen forms depends on the particular converter type.
