Type Mounting position
M1 M2 M3 M4 M5 M6
Z.49 0.55 1.9 1.9 1.9 1.8 0.65
Z.59 0.65 2 1.9 1.9 1.9 0.6
Z.69 0.65 2.1 2.6 2.6 2.3 0.85
Z.79 1.1 3.8 3.9 3.9 3.7 1.4
Z.89 2.2 6.9 6.7 6.7 6.6 2.4
12.3.32.2 Parallel shaft gearbox
Table 12-51 Oil quantitiesin l for FD/Z, FD/ZZ, FD/ZA., FD/ZAF., FD/ZAZ., FD/ZAD., sizes29-89
Type Mounting position
M1 M2 M3 M4 M5 M6
FD.29 0.6 0.8 0.35 0.6 0.45 0.45
FD.39 0.95 1.1 0.7 1.2 0.8 0.8
FD.49 2.1 2.3 1.5 2.3 1.5 1.5
FD.69 2.2 2.7 1.6 2.7 1.8 1.8
FD.79 3 3.8 2.7 3.9 2.6 2.7
FD.89 5.6 7.6 5.9 7.8 5.1 5.2
FZ.29 0.6 0.9 0.4 0.7 0.5 0.45
FZ.39 0.95 1.3 0.8 1.4 0.9 0.85
FZ.49 1.6 2.5 1.6 2.5 1.6 1.6
FZ.69 2.2 2.8 1.6 2.9 1.9 1.9
FZ.79 2.8 4.1 2.9 4.2 2.7 2.9
FZ.89 4.9 7.7 5.9 8.4 5.2 5.5
Table 12-52 Oil quantitiesin l for FD/ZF, sizes29-89
Type Mounting position
M1 M2 M3 M4 M5 M6
FDF29 0.6 0.8 0.35 0.6 0.45 0.45
FDF39 1 1.2 0.75 1.3 0.8 0.85
FDF49 2.2 2.3 1.5 2.4 1.6 1.5
FDF69 2.4 2.8 1.6 2.9 1.9 1.9
FDF79 3.1 3.9 2.7 4 2.7 2.6
FDF89 5.8 7.6 5.8 8 5.2 5.2
FZF29 0.6 0.9 0.4 0.7 0.5 0.45
FZF39 1 1.4 0.85 1.6 0.95 0.9
FZF49 1.8 2.4 1.5 2.6 1.6 1.6
FZF69 2.4 2.9 1.6 3.1 2 2
FZF79 2.9 4.2 2.9 4.3 2.9 2.8
FZF89 5.1 7.7 5.8 8.6 5.3 5.4
