1055 Seal 1346 Parallel key
1065 Sealing cap 1401 Screw plug
1070 Sealing cap 1420 Vent 󹪝lter
1101 Output shaft 1430 Eyebolt
1105 Parallel key  
1130 Bearing  
1131 Shim  
1133 NILOS ring  
1135 Locking ring  
1140 Bearing  
1141 Supporting disk/shim  
1144 Supporting disk/shim  
1145 Locking ring  
1160 Shaft sealing ring  
1161 Shaft sealing ring  
1162 O ring  
1165 Seal  
1210 Bolt  
1212 Nut  
1225 Seal  
1301 Plug-in pinion  
1303 Slip-on pinion  
1304 Parallel key  
1305 Helical gear  
1306 Parallel key  
1308 Locking ring  
Figure12-70 Helical gearbox D/Z, sizes19-89
12.3.33.3 Parallel shaft gearbox F, sizes29-89
Note
For gearbox size 29, we recommend that Siemens AG replaces the gearbox if service is required.
Parts subject to wear are available on request.
Additional information on the SIMOGEAR geared motor
12.3Speci󹪝c data gearbox
