The motors have been built using state-of-the-art technology and are shipped in an
operationally reliable condition. Changes made by users could a󹪜ect this operational
reliability and are forbidden.
Note
The data on the rating plate assumes an installation altitude of up to 1000m above sea level.
The permissible ambient temperature is stamped on the rating plate.
In the case of other ambient temperatures and installation altitudes, contact Technical Support.
The motors have been designed for the application described in Section Technical data
(Page439). Do not operate the motor outside the speci󹪝ed power limit. Other operating
conditions must be contractually agreed.
Never use degrees of protection ≤IP54 outdoors. Air-cooled versions are designed for
ambient temperatures of ‑15°Cto+40°C as standard and for an installation altitude of
up to 1000m above sea level. Please note any deviations to the data on the rating plate.
Conditions at the location of use must comply with all speci󹪝cations on the rating plate.
Do not climb on the motor. Do not place any objects on the motor.
12.2.3 General technical description
The following directives and standards are relevant for the motor:
Table 12-9 Overview of the standards
Feature Standard
Dimensioning and operational behavior IEC60034‑1
Procedure for determining the losses and the e󹪟ciency of rotating
electrical machines and tests
IEC60034‑2‑1
IEC60034‑2‑2
Measuring the energy e󹪟ciency for converter operation IEC60034‑2‑3
Degree of protection IEC60034‑5
Cooling IEC60034‑6
Terminal marking and direction of rotation IEC60034‑8
Noise emission IEC60034‑9
Thermal protection IEC60034‑11
Starting characteristics, rotating electric motors IEC60034‑12
E󹪟ciency classi󹪝cation of three-phase squirrel-cage induction motors IEC60034‑30‑1
Energy e󹪟ciency class for converter motors (IE code) IECTS60034‑30‑2
IECstandard voltages IEC60038
Safety of machinery IEC60204‑1
The motor is equipped with grease-lubricated roller bearings. The bearings are permanently
lubricated.
The stator winding is designed for temperature class155 (F).
Additional information on the SIMOGEAR geared motor
12.2Speci󹪝c data motor
