2405 Spring washer 2513 Bracket
2406 Bearing 2516 Complete terminal board
2412 Potting compound 2517 Screw
2413 V-ring 2518 Screw retainer
2415 Brake 2521 Terminal connector
2416 Screw retainer 2522 Terminal strip
2417 Screw 2523 Screw
2418 Coupling driver 2530 Cable gland
2419 Locking ring 2531 Nut
2420 Supporting /adjusting washer 2532 Reduction / expansion
2421 Feather key 2533 Cable
2422 Dust protection ring 2534 Screw plug
2423 Manual release lever 2540 Recti󹪝er
2424 Shaft sealing ring 2601 Fan blade
2430 Complete bushing 2602 Tolerance ring
M430 Cable gland 2603 Locking ring
N430 Seal (O-ring) 2605 Fan cover
P430 Seal insert 2606 Screw retainer
2432 Friction disk 2607 Screw
2433 Friction plate 2615 Protective canopy
2437 Supporting /adjusting washer 2618 Damping disk
2438 Seal 2701 Feather key
2441 Supporting /adjusting washer 2702 Screw
2472 Shaft extension 2703 Screw retainer
12.3 Speci󹪝c data gearbox
12.3.1 General information gearbox
Note
Siemens does not accept any liability for damage and operational disturbances that result from
the non-observance of these operating instructions.
These operating instructions are included with the geared motor when delivered, or you can
󹪝nd them in SIOS (https://support.industry.siemens.com/cs/de/en/ps/13424/man). Read the
operating instructions before handling the geared motor. Carefully follow the instructions.
This is how you ensure safe and disturbance-free operation.
The geared motors described here correspond to state-of-the-art technology at the time
these operating instructions were printed.
Additional information on the SIMOGEAR geared motor
12.3Speci󹪝c data gearbox
SINAMICS G115D Wall Mounted distributed drive
Operating Instructions, 07/2023, FW V4.7 SP14, A5E52808211A AA 479
