An overview of all the parameters that belong to the command data sets is provided in the
List Manual.
Note
The converter requires approximately 4 ms to switch over the command data set.
Parameters
Parameter Description Setting
p0010 Drive commissioning parameter 󹪝l‐
ter
Set p0010 = 15 to change the data set.
Factory setting: 1
r0050.0...1 CO/BO: Command Data Set CDS ef‐
fective
Displays the number of the currently active com‐
mand data set
p0170 Number of command data sets
(CDS)
p0170 = 2, 3 or 4
Factory setting: 2
p0809[0...2] Copy command data set CDS [0] Source command data set
[1] Target command data set
[2] 0→1: Starts the copy operation
Factory setting: 0
p0810 BI: Command data set selection
CDS bit 0
Sets the signal source to select CDS bit 0.
Factory setting: dependent upon the converter
p0811 BI: Command data set selection
CDS bit 1
Sets the signal source to select CDS bit 1.
Factory setting: 0
7.11 Motor holding brake
Overview
The motor holding brake holds the motor in position when it is switched o󹪜.
When the "Motor holding brake" function is correctly set, the motor remains switched on as
long as the motor holding brake is open. The converter only switches the motor o󹪜 when the
motor holding brake is closed.
