You have now installed the GSDML in the engineering system of the controller.
❒
5.13.7 Connecting the converter to Ethernet/IP
Overview
To connect the converter to a control system via Ethernet, proceed as follows:
Procedure
1. Connect the converter to the control system via an Ethernet cable.
2. Create an object for data exchange.
You have the following options:
– Load the EDS 󹪝le into your controller if you want to use the ODVA pro󹪝le.
You can 󹪝nd the EDS 󹪝le on the Internet:
EDS (https://support.industry.siemens.com/cs/ww/en/view/78026217)
– If your controller does not accept the EDS 󹪝le, or if you wish to use the SINAMICS pro󹪝le,
you must create a generic module in your controller:
Creating generic I/O module (Page172)
You have connected the converter to the control system via Ethernet/IP.
❒
Example
You can 󹪝nd an example showing how to connect a converter to the control system via
Ethernet/IP on the Internet:
Application example (https://support.industry.siemens.com/cs/ww/en/view/82843076)
Further information
You can 󹪝nd information on routing and shielding Ethernet cables on the Internet:
Ethernet/IP (https://www.odva.org/wp-content/uploads/2020/05/
PUB00035R0_Infrastructure_Guide.pdf)
5.13.8 What do you need for communication via Ethernet/IP?
Check the communication settings using the following questions. If you answer "Yes" to the
questions, you have correctly set the communication settings and can control the converter via
the 󹪝eldbus.
• Is the converter correctly connected to the Ethernet/IP?
• Is the EDS 󹪝le installed in your control system?
