Siemens SINAMICS G115D

Parameter Description Setting
... ... ...
p1015[0...n] CO: Fixed speed setpoint 15 [rpm] Fixed speed setpoint 15
Factory setting: 0 rpm
p1016 Fixed speed setpoint selection
mode
Fixed speed setpoint mode
Factory setting: 1
1: Direct
2: Binary
p1020[0...n] Fixed speed setpoint selection, bit 0 Fixed speed setpoint selection, bit 0
Factory setting: 0
p1021[0...n] Fixed speed setpoint selection, bit 1 Fixed speed setpoint selection, bit 1
Factory setting: 0
p1022[0...n] Fixed speed setpoint selection, bit 2 Fixed speed setpoint selection, bit 2
Factory setting: 0
p1023[0...n] Fixed speed setpoint selection, bit 3 Fixed speed setpoint selection, bit 3
Factory setting: 0
r1024 Fixed speed setpoint active Fixed speed setpoint is active.
r1025.0 Fixed speed setpoint status Fixed speed setpoint status
1 signal: Fixed speed setpoint is selected.
Further information
Additional information about binary and direct selection can be found in function diagrams
3010 and 3011 in the List Manual.
7.18 Setpoint processing
7.18.1 Overview
Overview
Setpoint processing in󹪞uences the setpoint using the following functions:
• "Invert" inverts the motor direction of rotation.
• The "Inhibit direction of rotation" function prevents the motor from rotating in the incorrect
direction; this function can make sense for conveyor belts, extruders, pumps and fans, for
example.
• The "Skip frequency bands" prevent the motor from being continuously operated within
these skip bands. This function avoids mechanical resonance e󹪜ects by only permitting the
motor to operate brie󹪞y at speci󹪝c speeds.
Advanced commissioning
7.18Setpoint processing
SINAMICS G115D Wall Mounted distributed drive
Operating Instructions, 07/2023, FW V4.7 SP14, A5E52808211A AA 265
