1043 Plug 1212 Nut
1044 Plug 1225 Seal
1045 Bolt 1301 Plug-in pinion
1050 Housing cover 1303 Slip-on pinion
1051 Bolt 1304 Parallel key
1055 Seal 1305 Helical gear
1065 Sealing cap 1306 Parallel key
1070 Sealing cap 1307 Spacer/bush
1091 Rubber bush 1308 Locking ring
1093 Plug 1309 Seal
1101 Output shaft 1315 Bearing
1102 Bushing 1320 Bearing
1104 Seal 1321 Locking ring
1105 Parallel key 1325 Pinion shaft
1114 Cover NDE 1330 Helical gear
1115 Seal 1331 Parallel key
1116 Bolt 1340 Pinion shaft
1117 Screw lock 1345 Helical gear
1118 Plug/sealing cap 1346 Parallel key
1120 Shrink disk 1401 Screw plug
1121 Protective cap 1410 Mounting accessories
1129 Supporting disk 1411 Bolt
1130 Bearing 1412 Locking ring
1131 Shim 1413 Disk
1132 Bushing 1415 Locking ring
1133 NILOS ring 1418 Sealing cap
1135 Locking ring 1420 Vent 󹪝lter
1138 Locking ring  
1139 Supporting disk  
1140 Bearing  
1141 Supporting disk/shim  
Figure12-71 Parallel shaft gearbox F, sizes29-89
12.3.33.4 Bevel gearbox B, sizes19-49
Note
For gearbox sizes19 and 29, Siemens recommends replacement of the gearbox if service is
required.
Parts subject to wear are available on request.
