Siemens SINAMICS G115D

• Shielded motor cable with low capacitance
• Shielded external braking resistor cable with low capacitance
• Pulse frequency ≤ factory setting
• Converters with integrated C2 line 󹪝lter
Note
The SINAMICS G115D converter is designed for operation in the second environment (industrial
area) and may not be used in the 󹪝rst environment (residential area) unless the appropriate
noise suppression measures have been adopted.
Note
A power drive system consisting of multiple units connected together in daisy-chain may require
further measures to meet EMC requirements.
Harmonic currents
Frame
size
Typical Harmonic current (% of rated input current) at U
K
1%
5th 7th 11th 13th 17th 19th 23rd 25th
FSA 15.65 11.65 7.18 6.19 4.50 4.30 3.12 3.53
FSB 16.79 12.36 7.52 6.75 4.79 4.56 3.30 3.65
FSC 18.45 13.30 8.20 7.29 5.23 5.07 3.85 3.93
Note
Units installed within the categoryC2 (domestic) environment require supply authority
acceptance for connection to the public low-voltage power supply network. Please contact your
local supply network provider.
Units installed within the categoryC3 (industrial) environment do not require connection
approval.
11.5 Protecting persons from electromagnetic 󹪝elds
Overview
Protection of workers from electromagnetic 󹪝elds is speci󹪝ed in the European EMF Directive
2013/35/EU. This directive is implemented in national law in the European Economic Area (EEA).
Employers are obligated to design workplaces in such a way that workers are protected from
impermissibly strong electromagnetic 󹪝elds.
To this end, assessments and/or measurements must be performed for workplaces.
Technical data
11.5Protecting persons from electromagnetic 󹪝elds
SINAMICS G115D Wall Mounted distributed drive
424 Operating Instructions, 07/2023, FW V4.7 SP14, A5E52808211A AA
