Precondition
1. The laws for protection from electromagnetic 󹪝elds in force in individual EU member states
can go beyond the minimum requirements of the EMF Directive 2013/35/EU and always take
precedence.
2. The ICNIRP 2010 limits for the workplace are the basis for the assessment.
3. The 26th BImSchV (German Federal Emission Protection Regulation) de󹪝nes 100μT (RMS)
for the assessment of active implants. According to Directive 2013/35/EU, 500μT (RMS) at
50Hz is applicable here.
4. Compliance with the limit values was assessed for the following frequencies:
– Line frequency 47Hz to63 Hz
– Pulse frequency, for example 4/8/16 kHz and multiples thereof, assessed up to a
maximum of 100kHz
5. The routing of power cables has a signi󹪝cant impact on the electromagnetic 󹪝elds that occur.
Install and operate the components inside metallic cabinets in compliance with the
documentation and use shielded motor cables.
EMC installation guidelines (Page49)
Description
The following information regarding electromagnetic 󹪝elds relates solely to converters supplied
by Siemens.
The converters are normally used in machines. The assessment and testing is based on DIN
EN 12198.
The indicated minimum distances apply to the head and complete torso of the human body.
Shorter distances are possible for extremities.
 Individuals without active implants Individuals with active implants
Minimum distances to
the converter
Forearm length (approx. 35cm) Must be separately assessed depend‐
ing on the active implant.
