Siemens SINAMICS G115D

I&M
data
Format Explanation Associated pa‐
rameters
Example for
the content
I&M3 Visible String [54] Any comment p8808[0…53] -
I&M4 Octet String[54] Check signature to track changes
for Safety Integrated.
This value can be changed by the
user.
The test signature is reset to the
value generated by the machine is
p8805=0 is used.
p8809[0…53] Values of
r9781[0] and
r9782[0]
When requested, the converter transfers its I&M data to a higher-level control or to a PC/PG
with installed Startdrive.
I&M0
Designation Format Example for the con‐
tent
Valid for PROFI‐
NET
Manufacturer-speci󹪝c u8[10] 00…00hex ---
MANUFACTURER_ID u16 42dhex (=Siemens) ✓
ORDER_ID Visible String [20] „6SL3246-0BA22-1FA
0“
✓
SERIAL_NUMBER Visible String [16] „T-R32015957“ ✓
HARDWARE_REVISION u16 0001 hex ✓
SOFTWARE_REVISION char, u8[3] „V“ 04.70.19 ✓
REVISION_COUNTER u16 0000 hex ✓
PROFILE_ID u16 3A00hex ✓
PROFILE_SPECIFIC_TYPE u16 0000 hex ✓
IM_VERSION u8[2] 01.02 ✓
IM_SUPPORTED bit[16] 001Ehex ✓
9.4 Alarms, alarm bu󹪜er, and alarm history
Overview
An alarm generally indicates that the converter may no longer be able to maintain the operation
of the motor in future.
The extended diagnostics have an alarm bu󹪜er and an alarm history, in which the converter
stores the most recent alarms.
Alarms, faults and system messages
9.4Alarms, alarm bu󹪜er, and alarm history
SINAMICS G115D Wall Mounted distributed drive
374 Operating Instructions, 07/2023, FW V4.7 SP14, A5E52808211A AA
