8.1.4 Activating message for a memory card that is not inserted
Function
The converter identies whether a memory card is not inserted, and signals this state. The
message is deactivated in the converter factory setting.
Activate message
Procedure
1. Set p2118[x]=1101, x=0, 1,…19
2. Set p2119[x]=2
Message A01101 for a memory card that is not inserted is activated.
❒
To cyclically signal to a higher-level control that a memory card is not inserted, interconnect
parameter r9401 to the send data of a PROFIdrive telegram of your choice.
Deactivate message
Procedure
1. Set p2118[x]=1101, x=0, 1,…19
2. Set p2119[x]=3
Message A01101 for a memory card that is not inserted is deactivated.
❒
Parameters
Parameter Description Setting
p2118[0…19] Change message type, mes‐
sage number
Selects faults or alarms for which the message
type should be changed.
Factory setting: 0
p2119[0…19] Change message type
Sets the message type for the selected fault or
alarm.
1: Fault (factory setting)
2: Alarm
3: No message
r9401 Safely remove memory card
status
Displays the status of the memory card.
Bit 00: Memory card inserted
Bit 01: Memory card activated
Bit 02: Siemens memory card
Bit 03: Memory card used as USB data storage
medium from the PC
Data backup and series commissioning
8.1Transferring settings using a memory card
SINAMICS G115D Wall Mounted distributed drive
Operating Instructions, 07/2023, FW V4.7 SP14, A5E52808211A AA 357
