Siemens SINAMICS G115D

 G Pre󹪝x G115D
022 Converter power
M Motor Mounted
W Wall Mounted
Communication
IO I/O variant
ASi ASi version
PN Pro󹪝net version
- Always "-" for Wall Mounted
Options
L Standard brake, world brake
G Enclosed brake
H, HA Manual brake release, lockable manual brake release
12.1.14.2 Gearbox type designation
Table 12-6 Example of the article number structure
SIMOGEAR gearbox Article number position
1 2 3 4 5
Helical gearbox E 2 K J 8 0
Helical gearboxD 2 K J 8 2
Helical gearboxZ 2 K J 8 1
Parallel shaft gearboxFD 2 K J 8 4
Parallel shaft gearboxFZ 2 K J 8 3
Bevel gearboxB,K 2 K J 8 5
Helical worm gearboxC 2 K J 8 6
Table 12-7 Example of the type designation structure


Example:
Main gearbox
F D F 89
Gearbox type F   
Stage  D  
Type   F 
Size    89
Table 12-8 Type designation code
Gearbox type
(-) Helical gearbox
F Parallel shaft gearbox
Additional information on the SIMOGEAR geared motor
12.1General information geared motor with SINAMICS G115D Motor Mounted / Wall Mounted
SINAMICS G115D Wall Mounted distributed drive
440 Operating Instructions, 07/2023, FW V4.7 SP14, A5E52808211A AA
