• PWE1, bit 0…15:= 0 hex
• PWE2, Bit 0…15: =1A hex (26 = 1A hex)
3DUDPHWHUFKDQQHO
3:(KLJKUGZRUG3:(ORZWKZRUG
,1'QGZRUG
3DJHLQGH[3DUDPHWHUQXPEHU6XELQGH[3DUDPHWHUYDOXHELW3DUDPHWHUYDOXHELW
3.(VWZRUG
$.





Write request: assign digital input 2 with the function ON/OFF1 (p0840[1] = 722.2)
In order to link digital input 2 with ON/OFF1, you must assign parameter p0840[1] (source,
ON/OFF1) the value 722.2 (DI2). To do this, you must populate the telegram of the
parameter channel as follows:
• PKE, bit 12 … 15 (AK): = 7 (change parameter value (󹪝eld, word))
• PKE, bit 0 … 10 (PNU): = 348 hex (840 = 348 hex, no o󹪜set, as 840 < 1999)
• IND, bit 8…15 (subindex): = 1 hex (CDS1 =Index 1)
• IND, bit 0…7 (page index): = 0 hex (o󹪜set 0 corresponds to 0 hex)
• PWE1, Bit 0…15: = 2D2 hex (722=2D2 hex)
• PWE2, Bit 10…15: = 3F hex (drive object - 63 = 3F hex)
• PWE2, Bit 0…9: = 2 hex (Index of Parameter (DI2 =2))
3DUDPHWHUFKDQQHO
3:(KLJKUGZRUG3:(ORZWKZRUG
,1'QGZRUG
3DJHLQGH[3DUDPHWHUQXPEHU6XELQGH[3DUDPHWHUYDOXH
3.(VWZRUG
'ULYH2EMHFW,QGH[$.







7.5.8 Expanding or freely interconnecting telegrams
Overview
When you have selected a telegram, the converter interconnects the corresponding signals with
the 󹪝eldbus interface. Generally, these interconnections are locked so that they cannot be
changed. However, with the appropriate setting in the converter, the telegram can be extended
or even freely interconnected.
