Siemens SINAMICS G115D

Property Explanation
Installation altitude Up to 1000m above sea level without derating
Above 1000m (up to 4000m) with derating
Torque derating as a function of the installation altitude (Page418)
Cooling method
• FSA/FSB (2.2 kW to 3 kW): Natural convection cooling
• FSB (4 kW)/FSC: Air cooling with integrated fan
Cooling air Clean and dry air
Degree of protec‐
tion
2)
Glanded variant:
• IP66, indoor and outdoor use, has to be protected from direct weather conditions
according to EN IEC 60721-3-3
Indoor use only according to UL Type 4X
(IP65/UL Type 4X indoor use only if the converter has Q8/0 connector at interface
X2 or the optional integrated repair switch)
Connector var‐
iant:
• IP65, indoor and outdoor use, has to be protected from direct weather conditions
according to EN IEC 60721-3-3
Indoor use only according to UL Type 4X
(IP65/No UL Type if the converter has MQ 15X or QUICKON connector at interface
X1)
Siemens recommends that you use the cables and connectors given in the linked chapter below to satisfy
the suitable rating of the UL enclosed type.
Cables and connectors (Page64)
1)
For UL-compliant applications, the maximum surrounding temperature for a glanded variant with daisy chain is 48 °C.
2)
For the speci󹪝c degree of protection of your converter, refer to the rating plate on your component.
11.1.2 Technical data of inputs and outputs
The technical data of inputs and outputs for G115D wall-mounted converter are the same with
that of G115D converter with geared motors. For details, see Chapter "AUTOHOTSPOT".
11.1.3 Technical data dependent upon the power
Frame size Rated power (kW) Output current
(A)
Input current (A) Power loss (W)
FSA 0.37 1.3 1.23 33.73
0.55 1.7 1.58 37.61
0.75 2.2 1.99 43.10
1.1 3.1 2.69 53.58
1.5 4.1 3.48 66.99
FSB 2.2 5.9 5.18 95.96
3 7.7 6.76 125.82
4 10.2 8.95 172.89
FSC 5.5 13.2 11.88 170.85
7.5 19 17.11 245.54
Technical data
11.1Technical data of the G115D wall-mounted converter
SINAMICS G115D Wall Mounted distributed drive
Operating Instructions, 07/2023, FW V4.7 SP14, A5E52808211A AA 413
