Siemens SINAMICS G115D

Property Explanation
Earth fault current The converter can be operated with a typeB 300mA RCD.
Electromechanical (EM) brake
• 180 V DC
– Rated current: 0.8A
– Disconnection on the DC side permits "fast" braking
• 400 V AC (optional, for wall-mounted converter only)
– Rated current: 1A
1)
For IT system, only permissible when the functional grounding in the converter has been removed.
Safety Integrated
Property Explanation
Safety function STO and SLS
 STO and SLS ful󹪝l the requirements of the following standards:
• SIL 2 according to IEC61508, part 1 to 3 (2010)
• PLd according to IEC61800-5-2 (2016)
• Category 3 according to ISO13849 part 1 (2015)
The function STO corresponds to stop category 0 according to IEC60204 (2005). STO
is always prioritized higher than SLS.
Response Time
The response times for the Safety Integrated functions can be found under:
Safety Integrated response times (https://support.industry.siemens.com/cs/gb/en/
view/109782490)
Probability of failures
The PFH values can be found under:
PFH values (https://support.industry.siemens.com/cs/ww/en/view/76254308)
Environmental conditions
Property Explanation
Surrounding tem‐
perature
Storage -40 °C to +70 °C, Class 1K4 according to IEC60721-3-1, in product packaging
Transport -40 °C to +70 °C, Class 2K4 according to IEC60721-3-2, in transport packaging
Operation -30 °C to +55 °C
1)
, Class 3K3 according to IEC60721-3-3
Power derated by 3%/K when > 40 °C
Current derating as a function of the surrounding temperature (Page419)
Vibration and
shock
Transport Class 2M3, test according to EN 60721-3-2
Operation Class 3M2, test according to EN 60721-3-3
Resistance to biologically active sub‐
stances
Class 3B1 according to EN 60721-3-3
Pollution degree Suitable for pollution degree 2 environment according to IEC 61800-5-1
Relative humidity < 95% (non-condensing, no icing, no salt spray)
Technical data
11.1Technical data of the G115D wall-mounted converter
SINAMICS G115D Wall Mounted distributed drive
412 Operating Instructions, 07/2023, FW V4.7 SP14, A5E52808211A AA
