Table 12-29 Maximum load of the eyebolt on the gearbox
Thread size m d
3
Thread size m d
3
kg mm kg mm
M8 140 36 M20 1200 72
M10 230 45 M24 1800 90
M12 340 54 M30 3200 108
M16 700 63 - - -
The eyebolt corresponds to DIN580.
Procedure
1. Transport the gearbox or geared motor by the lifting eyes or eyebolts on the gearbox housing.
2. The lifting eyes and eyebolts are designed only for the weight of the gearbox or geared
motor. It is not permissible to add additional loads such as built-on parts on the gearbox to
the lifting eyes and eyebolts.
3. Remove any eyebolts that are no longer required after transport.
You have prepared the gearbox or geared motor for transport.
12.3.7 Storage
12.3.7.1 General information for storage
WARNING
Danger of serious injuries caused by falling objects
Danger of damage to the gearbox when stacked
Do not stack gearboxes or geared motors on each other.
NOTICE
Failure of the external protection
Mechanical damage, chemical damage and thermal damage, such as scratches, acids, alkalis,
sparks, welding beads and heat cause corrosion.
Do not damage the paint 󹪝nish.
Unless contractually agreed otherwise, the guarantee period for the standard preservative
lasts 6months from the date of delivery.
In the case of storage in transit over 6months, special arrangements must be made for
preservation. Contact Technical Support.
Store the gearbox or geared motor in dry, dust-free rooms that are maintained at a constant
temperature.
Additional information on the SIMOGEAR geared motor
12.3Speci󹪝c data gearbox
