Motor Minimum clearance of motor with G115D from wall for air intake
Motor Mounted Wall Mounted
x in mm
71 150 15
80 150 20
90 150 20
100 150 20
112 150 25
132 - 30
NOTICE
Collision of mounted components on the converter
With a projecting converter on Motor Mounted, care should be taken to avoid potential
collisions between the mounted components on the converter (connectors, cable entries etc.)
and neighboring components.
See mounting clearance of the converter (150mm) in section AUTOHOTSPOT.
The permissible coolant temperature (ambient temperature at installation location) is
‑15°Cto+40°C as standard for an installation altitude of up to 1000m above sea level.
Deviating data are specied on the rating plate.
Drives for ambient temperatures from ‑30°Cto+40°C and ‑20°Cto+55°C are available as
options.
When mounting in the vertical position with the fan cover facing upward, provide protection
to prevent foreign objects falling in, e.g. using an appropriate cover.
12.2.9 Condensation drain hole (optional)
When installing the surface-cooled motor, take care that the condensation drain holes are at the
lowest point.
12.2.10 Connecting the motor in the terminal box
For the Motor Mounted version, the converter is permanently connected to the motor. For the
connection of the converter to the electricity supply network, see previous chapters.
Additional information on the SIMOGEAR geared motor
12.2Specic data motor
SINAMICS G115D Wall Mounted distributed drive
452 Operating Instructions, 07/2023, FW V4.7 SP14, A5E52808211A AA
