12.1.2 Rating plate
The rating plate of the gearbox or geared motor is printed on a labeled polyester 󹪝lm or
optionally on a stainless steel rating plate. The rating plate is glued using a special masking 󹪝lm.
The 󹪝lm ensures permanent resistance to UV radiation and media of all kinds, such as oils,
greases, salt water and cleaning agents.
The adhesive and material ensure 󹪝rm adhesion and long-term readability throughout the
operating temperature range of the gearbox and geared motor.
The edges of the rating plate are paint-󹪝nished to match the color of the gearbox or motor to
which it is a󹪟xed.
12.1.3 Surface treatment
12.1.3.1 General information on surface treatment
All paint 󹪝nishes are sprayed on.
WARNING
Danger due to electrostatic discharge
For paint 󹪝nishes in explosion group III, the paint can be electrostatically charged as a result of
intensive dust turbulence or processes with high levels of electrostatic charging.
Risk of explosion as a result of processes with high levels of electrostatic charging
Minimize the risk of electrostatic charging by applying e󹪜ective measures according to
IEC60079-32-1.
NOTICE
Failure of the external protection
If the paint 󹪝nish is damaged, the geared motor may corrode.
Do not damage the paint 󹪝nish.
Note
Information about the ability to be repainted does not guarantee the quality of the paint product
supplied by your supplier.
Only the paint manufacturer is liable for the quality and compatibility.
Note
C1 paints are not suitable for ambient air temperatures below ‑20°C.
