Parameters
Conveyor technology control parameters (Page220)
7.9.1.2 Conveyor, one direction and two speeds (p3393 = 2)
Overview
With p3393 (conveyor technology application) set to 2, the converter enables the load on a
conveyor belt to move in one direction with variable speeds. Two sensors are required to signal
the limit positions for the motor to stop or decelerate.
Precondition
You interconnect the signals of the sensors with the digital inputs of your choice.
Advanced commissioning
7.9Conveyor technology control functions (for G115D PROFINET and AS-i variants only)
SINAMICS G115D Wall Mounted distributed drive
188 Operating Instructions, 07/2023, FW V4.7 SP14, A5E52808211A AA
