RP3 RP2 RP1 RP0 AS-i.P0=0 → alarm messages AS-i.P0=1 → faults
0 1 0 0 Overtemperature (A05000,
A05004, A05006, A07012,
A07015)
I
2
t overload (F30005, F07936)
0 1 0 1 Overvoltage (A30502, A07400) Equipment malfunction (F01000 to
F01257)
0 1 1 0 Local/Remote keyswitch in "O󹪜"
(A03560)
Not used
0 1 1 1 Undervoltage (A30016, A07402) Motor PTC sensor malfunction (F07011,
F07016)
1 0 0 0 I
2
t overload (A07805) Overvoltage (F30002, F30011)
1 0 0 1 Not used Not used
1 0 1 0 Local mode active (A03561) Not used
1 0 1 1 Not used Undervoltage (F30003, F07802)
1 1 0 0 Not used Short-circuit at the output (F30001,
F30017, F30021, F07801, F07807,
F07900)
1 1 0 1 Motor phase loss (A30015 *) Motor phase loss (F30015, F07902)
1 1 1 0 Not used Safety fault (F016xx)
1 1 1 1 Other alarms Other faults
* A30015 will be generated after the message type of F30015 is changed to "Alarm". For more information
on changing the message type, see p2118 and p2119 in the List Manual.
7.7.4 Cyclic and acyclic communication via CTT2
Via CTT2 (Combined Transaction Type 2), both cyclical and acyclical communication is
performed via AS-i. Because only one channel is available (AS-i.DO1 master → slave or AS-i.DI3
slave → master), a concurrent cyclical and acyclical data exchange is not possible.
The communication type (cyclical or acyclical) is always coded in the 󹪝rst byte in accordance
with the following table.
CTT2 commands
Code
(hex)
Explanation/meaning Followed by
Cyclic communication
Access to analog values via DS140 … DS147. See CP 343−2 / CP
343−2 P AS−Interface master, Chapter 4
CP 343−2 / CP 343−2 P AS−Interface master (https://
support.industry.siemens.com/cs/ww/en/view/5581657)
4 bytes: PWE1, PWE2
4 bytes: PWE1, PWE2
Acyclic communication - standard
10 hex Read request: Master → slave 2 bytes: Index, length
50 hex Read request OK: Slave → master Index, data
90 hex Read request failed: Slave → master 1 byte: Standard error code (3 hex)
11 hex Write request: Master → slave Index, length, data
51 hex Write request OK: Slave → master 
Advanced commissioning
7.7Drive control via AS-i
