1001 Gearbox housing 1225 Seal
1020 Bearing 1301 Plug-in pinion
1027 Locking ring / nut 1305 Helical
1030 Bearing 1306 Parallel key
1031 Supporting disk 1314 Screw lock
1032 Shim 1320 Bevel gear pair
1035 Locking ring 1346 Parallel key
1037 Locking ring 1401 Screw plug
1040 Output ange 1410 Mounting accessories
Additional information on the SIMOGEAR geared motor
12.3Specic data gearbox
