No. Description
06 hex Setting not permitted, only resetting (change request with a value not equal to 0 without
permission)
07 hex Descriptive element cannot be changed (change request to a descriptive element error
value that cannot be changed)
0B hex No master control (change request but with no master control, see also p0927.)
0C hex Keyword missing
11 hex Request cannot be executed due to the operating state (access is not possible for tempo‐
rary reasons that are not speci󹪝ed)
14 hex Inadmissible value (change request with a value that is within the limits but which is illegal
for other permanent reasons, i.e. a parameter with de󹪝ned individual values)
65 hex Parameter number is currently deactivated (depending on the mode of the converter)
66 hex Channel width is insu󹪟cient (communication channel is too small for response)
68 hex Illegal parameter value (parameter can only assume certain values)
6A hex Request not included / task is not supported (the valid request identi󹪝cations can be found
in table "Request identi󹪝cations controller → converter")
6B hex No change access for a controller that is enabled. (The operating state of the converter
prevents a parameter change)
86 hex Write access only for commissioning (p0010 = 15) (operating state of the converter pre‐
vents a parameter change)
87 hex Know-how protection active, access locked
C8hex Change request below the currently valid limit (change request to a value that lies within
the "absolute" limits, but is however below the currently valid lower limit)
C9hex Change request above the currently valid limit (example: a parameter value is too large for
the converter power)
CC hex Change request not permitted (change is not permitted as the access code is not available)
PNU (parameter number) and page index
The parameter number is located in value PNU in the 1st word of the parameter channel (PKE).
The page index is located in the 2nd word of the parameter channel (IND bit 7…0).
Parameter number PNU Page index
0000 … 1999 0000 … 1999 0hex
2000 … 3999 0000 … 1999 80hex
6000 … 7999 0000 … 1999 90hex
8000 … 9999 0000 … 1999 20hex
10000 … 11999 0000 … 1999 A0hex
20000 … 21999 0000 … 1999 50hex
30000 … 31999 0000 … 1999 F0hex
60000 … 61999 0000 … 1999 74 hex
Subindex
For indexed parameters, the parameter index is located in subindex (IND Bit15…8) as
hexadecimal value.
