No. Service Type Name Value/explanation
4 get UINT16 Revision The versions should match the EDS 󹪝le
5 get UINT16 Status See the following table
6 get UINT32 Serial number bits 0…19: consecutive number;
bits 20…23: Production identi󹪝er
bits 24 … 27: Month of manufacture (0 = Jan, B = Dec)
Bits 28…31: Year of manufacture (0=2002)
7 get Short
String
Product name Max. length 32 bytes
Explanation of No. 5 of the previous table
Byte Bit Name Description
1 0 Owned 0:Converter is not assigned to any master
1:Converter is assigned to a master
1  Reserved
2 Con󹪝gured 0:Ethernet/IP basic settings
1:Modi󹪝ed Ethernet/IP settings
For G120, always = 1
3  Reserved
4…7 Extended Device
Status
0:Self-test or status not known
1:Firmware update active
2:At least one I/O connection with error
3:No I/O connections
4:Incorrect con󹪝guration in the ROM
5:Fatal fault
6:At least one I/O connection is active
7: All I/O connections in the quiescent state
8 … 15: Reserved
2 8…11  Not used
12…15  Reserved
Assembly Object, Instance Number: 4 hex
Supported services
Class • Get Attribute single Instance • Get Attribute single
• Set Attribute single
Class Attribute
No. Service Type Name
1 get UINT16 Revision
2 get UINT16 Max Instance
3 get UINT16 Num of Instances
Advanced commissioning
7.6Drive control via Ethernet/IP
