• Serial data transfer CTT2, four bytes cyclically or acyclically via PIV. The
reading and writing of parameters is possible via the PIV. Because data
is transferred bit-by-bit, the read and write process is very slow.
→ AS-i.DI2
• Time signal for the CTT2 transfer to the AS-i master → AS-i.DI3
Cyclic and acyclic communication via CTT2 (Page180)
Macro 34: AS-i Dual Slave with 󹪝eldbus setpoint
The control accesses the two slaves of the converter each via four bits.
Via Slave 2, in accordance with pro󹪝le 7.A.E, the control speci󹪝es the commands listed below
(AS-i.DO0 …AS-i.DO2).
Via Slave 1, the control sends the command for quick stop and the data in cyclical or acyclical
mode.
The control requires one bit per slave in order to specify the slave.
Macro 34, Slave 2 with pro󹪝le 7.A.E: Control → Converter
• AS-i.DO0 → ON / OFF 1
• AS-i.DO1 → OFF 2
• AS-i.DO2 → Acknowledge fault
• AS-i.DO3 → Select Slave A or Slave B, interconnected internally
If the control speci󹪝es the speed setpoint, the converter replies:
Macro 34, Slave 2 with pro󹪝le 7.A.E: Converter → control
• p2080[0] = 53.13 PLC ready to switch on → AS-i.DI0
• p2080[1] = 899.11 Pulses enabled → AS-i.DI1
• p2080[2] = 722.0 State DI0 → AS-i.DI2
• p2080[3] = 722.1 State DI1 → AS-i.DI3
If the control sends a diagnostic request via AS-i.P0, the converter replies with the currently
pending fault or alarm messages.
Alarm and fault messages via RP0… RP3 from the converter to the AS-i master
(Page178)
Macro 34, Slave 1 with pro󹪝le 7.A.5: Control → Converter
• AS-i.DO0 → Time signal for the CTT2 transfer from the AS-i master
• AS-i.DO1 → Data bit for the CTT2 transfer, four bytes cyclically or acyclically via PIV.
The reading and writing of parameters is possible via the PIV. Because
data is transferred bit-by-bit, the read and write process is very slow.
• AS-i.DO2 → p3390 = 2093.4 Override quick stop
• AS-i.DO3 → Select Slave A or Slave B, interconnected internally
Advanced commissioning
7.7Drive control via AS-i
