Siemens SINAMICS G115D

General fault
PROFINET
Communication
Digital inputs and
outputs
130'*/&5"4J*0
Safety Integrated
Explanation of symbols for the following tables
LED is ON
LED is OFF
V
LED 󹪞ashes slowly
V
LED 󹪞ashes quickly
LED 󹪞ashes with variable frequency
Please contact Technical Support for LED states that are not described in the following.
Basic states
RDY Explanation
Temporary state after the supply voltage is switched on
The converter is free of faults
Commissioning or reset to factory settings
Alarms, faults and system messages
9.1Status LED overview
SINAMICS G115D Wall Mounted distributed drive
370 Operating Instructions, 07/2023, FW V4.7 SP14, A5E52808211A AA
