PROFINET 󹪝eldbus
ACT LNK Explanation
Communication via PROFINET is error-free. Converter and open-loop control ex‐
change actual data
The converter is establishing communication with a higher-level control or a PG/PC
with Startdrive installed
A physical connection has been set up
Communication via PROFINET is not active
Digital inputs and digital inputs/outputs
DI &
DI/O
Explanation
The associated digital input or digital input/output has the "high" state
The associated digital input or digital input/output has the "low" state
AS-i 󹪝eldbus
AS-i /
FLT
Explanation
System OK
AS-i master not connected or 󹪝rmware update failed

The 󹪝eldbus is improperly con󹪝gured
RDY In conjunction with a synchronously 󹪞ashing LED RDY:
Converter waits until the power supply is switched o󹪜 and switched on again after a
󹪝rmware update
No communications between processors within the converter
RDY In conjunction with an asynchronously 󹪞ashing LED RDY:
Incorrect memory card
Slave address 0
Converter trip
Firmware update is active
Alarms, faults and system messages
9.1Status LED overview
