The SAM interface kit is designed with a rubber support and magnets, which allows you
to easily mount the SINAMICS G120 Smart Access to the converter or remove it from the
converter. The permissible operating temperature range for the SAM interface kit is from -10
°C to +60 °C. Vibration in operation fullls Class 3M1 according to EN60721-3-3: 1995.
①, ② Magnetic side
③ Rubber support
Scope of delivery
• SAM interface kit for the SINAMICS G115D converter
• Compact Installation Instructions in English, Chinese, and German
Further information
For more information about mounting the G120 Smart Access to the G115D converter via the
optional SAM interface kit, see the SINAMICS G120 Smart Access Operating Instructions.
Overview of the manuals (Page588)
Overview of the SINAMICS G115D drive
3.4Optional components
SINAMICS G115D Wall Mounted distributed drive
38 Operating Instructions, 07/2023, FW V4.7 SP14, A5E52808211A AA
