Figure12-13 G115D motor frame sizes 71 - 112

Spare parts list for motor frame sizes 71-132

1401 Screw plug 2516 Complete terminal board

1420 Vent 󹪝lter 2517 Screw

2102 Stator 2518 Screw retainer

2200 Rotor 2519 Nut

2301 End shield 2521 Terminal connector

2305 Shim 2522 Terminal strip

2306 Bearing 2523 Screw

Additional information on the SIMOGEAR geared motor

12.2Speci󹪝c data motor

SINAMICS G115D Wall Mounted distributed drive

476 Operating Instructions, 07/2023, FW V4.7 SP14, A5E52808211A AA
