Note
The SIMOLOC assembly system secures the hollow shaft axially on the machine shaft.
Note
In the hollow shaft ⑥, oil the locating hole for the tapered bushing ⑨ and bronze bushing ②
lightly with the provided oil.
Oil type of the provided oil: CLPVG68DIN51517‑3
Note
The thrust collar⑤ must be placed at the correct position as in the delivered state.
Note
Before installing the SIMOLOC, mount the torque arms⑦ on the gearbox.
Additional information on the SIMOGEAR geared motor
12.3Speci󹪝c data gearbox
