Figure12-42 Mounting positions for helical gearbox DF/ZF ange-mounted design and DZ/ZZ with
housing ange, sizes19-29
Additional information on the SIMOGEAR geared motor
12.3Specic data gearbox
SINAMICS G115D Wall Mounted distributed drive
534 Operating Instructions, 07/2023, FW V4.7 SP14, A5E52808211A AA
