1001 Gearbox housing 1210 Screw
1020 Bearing 1212 Nut
1025 Locking ring 1225 Seal
1027 Locking ring 1301 Plug-in pinion
1030 Bearing 1305 Helical
1035 Locking ring 1306 Parallel key
1036 Support ring/shim 1340 Pinion shaft
1037 Locking ring 1345 Helical
1040 Output ange 1346 Parallel key
Additional information on the SIMOGEAR geared motor
12.3Specic data gearbox
