End customer
Overview diagram of the machine and/or system:
Converter data
The converter data include the hardware version of the safety-relevant converter.
Labeling the drive Article number and hardware version of the converter
Function table
The active safety functions depending on the operating mode and safety equipment are shown
in the function table.
Operating
mode
Safety equipment Drive Selected safety function Checked
Table A-1 Example of a function table
Operating
mode
Safety equipment Drive Selected safety function Checked
Automatic Protective door closed Conveyor belt --- ---
Protective door open Conveyor belt STO
Emergency Stop button
pressed
Conveyor belt STO
Acceptance test reports
File name of the acceptance reports
Appendix
A.2Acceptance tests for the safety functions
