Setup
3.6 Local display
FST030
222 Function Manual, 04/2017, A5E35693328-AA
This parameter is only available if
is set to Six Values or Six Diagnostic Values.
Setup → Display → View 4 → 6th value
Trend scale mode
Description
The
can be selected with automatic scaling or fixed scaling.
This parameter is only available if
is set to Totalizer or 1 Value and Graph.
If Fixed is selected,
and
must be
configured.
Setup → Display → View 4 → Trend Scale Mode
Trend log time window
Description
The
logging period (time axis length) can be selected.
1 Minute; 5 Minutes; 15 Minutes; 30 Minutes; 1 Hour; 2 Hours; 3 Hours
This parameter is only available if
is set to Totalizer or 1 Value and Graph.
Setup → Display → View 4 → Trend log time window
Trend scale lower limit
Description
The
defines the scaling lower limit of the value axis for the fixed
mode.
