Xerox WorkCentre 6605 Service Manual

Error Troubleshooting
Xerox Internal Use Only Phaser 6600 and WorkCentre 6605
Service Manual
2-15
Print Info Info Page Prints the printer configuration information on A4
paper.
2-33
Print Settings Prints the printer setting information on A4 paper. 2-34
Installation Serial No. Displays/specifies the serial number. 2-35
PagePack Displays the current PagePack status (Enable or
Disable).
HexDump Specifies whether to set HexDump to ON or OFF.
Tone Correction
(IOT tone correction)
Specifies whether to set IOT Tone Correction to ON or
OFF.
Pixel Counter Displays the last print pixel coverage (%) for 4 mm
square meter in A4 paper, per Y/M/C/K color.
Configuration Operates the DIP switches on the NVM in ESS.
XCPT Mode Displays/Specifies the XCPT Mode setting.
Print
Counter
Print Service Displays the current count of the Print Service.
Copy Service Displays the current count of the Copy Service.
FAX Service Displays the current count of the FAX Service.
Scan Service Displays the current count of the Scan Service.
Copy Counter M to B Copies the Master NVM values to the Backup NVM.
Copy Counter B to M Copies the Backup NVM values to the Master NVM.
Clear All NVM Initializes NVM.
Clear JobHistory Initializes the job data (log).
Clear AuditronPV Clears the AuditronPV data such as billing counter, user
account and user restriction settings.
Hard Drive Erase
(when the optional HD is
installed)
Deletes all data from the Hard Disk.
Clear DeviceData Deletes all data in the devices (EEPROM, SRAM, Fax
Memory, Hard Disk).
Printer Diag Function Names and Details
Function Description See

Xerox WorkCentre 6605 Specifications

General

Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Print Resolution	Up to 600 x 600 x 4 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Standard Paper Capacity	550 sheets
Maximum Paper Capacity	1, 250 sheets
Paper Output	250 sheets
Duplex Printing	Yes
Processor	533 MHz
Memory (Standard)	512 MB
Memory (Maximum)	1 GB
Monthly Duty Cycle	Up to 80, 000 pages
Type	Multifunction
Copy Speed	Up to 36 cpm black and color
Fax Resolution	300 x 300 dpi
Media Sizes	Letter, Legal, A4, A5, B5, Custom sizes
Connectivity	USB 2.0, Ethernet
Mobile Printing	Apple AirPrint
Operating System Compatibility	Windows, Mac, Linux
Dimensions (W x D x H)	500 mm
Weight	29.6 kg
Print Speed	Up to 36 ppm (Black) / Up to 36 ppm (Color)
