Xerox WorkCentre 6605 Service Manual

Error Troubleshooting
Phaser 6600 and WorkCentre 6605 Xerox Internal Use Only
Service Manual
2-16
Test Print No Image IOT Prints the IOT built-in test pattern. 2-40
Pattern IOT Prints the IOT built-in test pattern.
Grid 2 ESS Prints the ESS built-in grid pattern.
Cyan 20% ESS Fills one side of paper in the density of 20 % of cyan.
Magenta 20% ESS Fills one side of paper in the density of 20 % of
magenta.
Yellow 20% ESS Fills one side of paper in the density of 20 % of yellow.
Black 20% ESS Fills one side of paper in the density of 20 % of black.
CMY 20% ESS Fills one side of paper in the density of 20 % of the
mixture of cyan, magenta, and yellow.
Gradation ESS Prints the ESS built-in gradation pattern.
Toner Pallet Check Prints four bars, filled with 100% density of each color
(C/M/Y/K), lined on the paper.
* Use this for checking the density of each toner
cartridge.
Contamination Chk Prints 5 sheets of paper with the pattern of millimeter
scale on the top/left edges and inch scale on the
bottom/right edges, each filed with Y/M/C/K color of
20% density, and the one that identifies defects.
Parameter Regi Displays/specifies the Regi current set value. 2-52
Life Displays the current counter of the consumables life. 2-53
Print Prints the parameter of the IOT and the error count. 2-54
Exit Mode Exit Mode Exits Service Mode and restarts the printer.
Printer Diag Function Names and Details
Function Description See

Xerox WorkCentre 6605 Specifications

General

Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Print Resolution	Up to 600 x 600 x 4 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Standard Paper Capacity	550 sheets
Maximum Paper Capacity	1, 250 sheets
Paper Output	250 sheets
Duplex Printing	Yes
Processor	533 MHz
Memory (Standard)	512 MB
Memory (Maximum)	1 GB
Monthly Duty Cycle	Up to 80, 000 pages
Type	Multifunction
Copy Speed	Up to 36 cpm black and color
Fax Resolution	300 x 300 dpi
Media Sizes	Letter, Legal, A4, A5, B5, Custom sizes
Connectivity	USB 2.0, Ethernet
Mobile Printing	Apple AirPrint
Operating System Compatibility	Windows, Mac, Linux
Dimensions (W x D x H)	500 mm
Weight	29.6 kg
Print Speed	Up to 36 ppm (Black) / Up to 36 ppm (Color)
