Xerox WorkCentre 6605 Service Manual

Error Troubleshooting
Xerox Internal Use Only Phaser 6600 and WorkCentre 6605
Service Manual
2-25
Sensor Test Example
This section explains Digital Input Testing using [041-302: Front Cover Sensor] as an example.
1. Enter Service Mode. See “How To Enter Service Mode” on page 2-8.
2. Confirm that the [Printer Diag] is selected, and then press the OK button.
3. Use the [ ] button to select [Engine Diag], and press the OK button.
4. Press the OK button.
5. Use the [ ] or [ ] button to select [041-302].
6. Press the OK button.
7. Open and shut the front cover to check that the display changes as shown below.
8. Press the Back button to stop the test.
9. Press the Back button to return to the [Printer Diag] screen.
10. Exit Service Mode. See “How to Exit Service Mode” on page 2-10.
Monitor Test
Digital Output checks whether the digital output (DO) components function properly.
You can switch each DO component to ON and check the operation separately, which helps you judge
which component functions normally.
You can operate all components at one time in the Digital Output Test. If you open the interlock while
a motor test is being executed, the operation of each component will be stopped.
Note: Except for 010-001, 042-001, 042-002, set LVPS 24V to On (041-001) first.
Printer Diag
Engine Diag
Engine Diag
Sensor Test
Engine Diag
Sensor Test
Sensor Test
010 - 200 OFF
Sensor Test
041-302 OFF
Sensor Test
041-302 L 00
Sensor Test
041-302 H 00
Sensor Test
041-302 L 01
Cover Open Cover Close
Sensor Test
041-302 OFF
Printer Diag
Engine Diag

Xerox WorkCentre 6605 Specifications

General

Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Print Resolution	Up to 600 x 600 x 4 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Standard Paper Capacity	550 sheets
Maximum Paper Capacity	1, 250 sheets
Paper Output	250 sheets
Duplex Printing	Yes
Processor	533 MHz
Memory (Standard)	512 MB
Memory (Maximum)	1 GB
Monthly Duty Cycle	Up to 80, 000 pages
Type	Multifunction
Copy Speed	Up to 36 cpm black and color
Fax Resolution	300 x 300 dpi
Media Sizes	Letter, Legal, A4, A5, B5, Custom sizes
Connectivity	USB 2.0, Ethernet
Mobile Printing	Apple AirPrint
Operating System Compatibility	Windows, Mac, Linux
Dimensions (W x D x H)	500 mm
Weight	29.6 kg
Print Speed	Up to 36 ppm (Black) / Up to 36 ppm (Color)
