Xerox WorkCentre 6605 Service Manual

Error Troubleshooting
Phaser 6600 and WorkCentre 6605 Xerox Internal Use Only
Service Manual
2-26
Monitor Test Parameter Table
Chain Link Component
010 001 Fusing Relay
041 001 Low Voltage Power Supply 24V
042 001 Main Fan (Normal)
042 002 Main Fan (Half)
061 001 ROS Motor
071 001 Main Motor (Normal)
071 002 Main Motor (Half)
071 004 Paper Transport Motor (Normal)
071 005 Paper Transport Motor (Half)
071 007 Bypass Tray Feed Solenoid
071 008 Tray1 Feed Clutch
071 009 Take Away2 Clutch
071 010 Regi Clutch
071 011 Exit Clutch
071 012 Exit Clutch2
071 013 Duplex Clutch
071 014 Option Feeder1 Motor (Normal)
071 015 Option Feeder1 Motor (Half)
071 017 Option Feeder2 Motor (Normal) (not in use)
071 018 Option Feeder2 Motor (Half) (not in use)
071 020 Option Feeder1 Feed Clutch
071 021 Option Feeder2 Feed Clutch (not in use)
071 022 Option Feeder1 Take Away Clutch
071 023 Option Feeder2 Take Away Clutch (not in use)
093 001 Developer Motor (Normal)
093 002 Developer Motor (Half)
093 004 Yellow Toner Dispense Motor (Normal)
093 005 Yellow Toner Dispense Motor (Half)
093 006 Magenta Toner Dispense Motor (Normal)
093 007 Magenta Toner Dispense Motor (Half)

Xerox WorkCentre 6605 Specifications

General

Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Print Resolution	Up to 600 x 600 x 4 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Standard Paper Capacity	550 sheets
Maximum Paper Capacity	1, 250 sheets
Paper Output	250 sheets
Duplex Printing	Yes
Processor	533 MHz
Memory (Standard)	512 MB
Memory (Maximum)	1 GB
Monthly Duty Cycle	Up to 80, 000 pages
Type	Multifunction
Copy Speed	Up to 36 cpm black and color
Fax Resolution	300 x 300 dpi
Media Sizes	Letter, Legal, A4, A5, B5, Custom sizes
Connectivity	USB 2.0, Ethernet
Mobile Printing	Apple AirPrint
Operating System Compatibility	Windows, Mac, Linux
Dimensions (W x D x H)	500 mm
Weight	29.6 kg
Print Speed	Up to 36 ppm (Black) / Up to 36 ppm (Color)
