Xerox WorkCentre 6605 Service Manual

Error Troubleshooting
Xerox Internal Use Only Phaser 6600 and WorkCentre 6605
Service Manual
2-27
Monitor Test Example
This section explains Digital Output Testing using [071-002: Main Motor (Half)] and [071-010: Regi
Clutch] as an example.
1. Enter Service Mode. See “How To Enter Service Mode” on page 2-8.
2. Confirm that the [Printer Diag] is selected, and then press the OK button.
3. Use the [ ] button to select [Engine Diag], and press the OK button.
4. Use the [ ] button to select [Monitor Test], and press the OK button.
5. To set LVPS 24V to On, use the [ ] or [ ] button and select [041-001]
.
6. Press the OK button, and check the operation sound
.
7. To carry on checking the operation of Main Motor (Half), do not press the Back button. Use the
[ ] or [ ] button to display [071-002].
8. Press the OK button, and check the operation sound.
Note: Press the Back button to stop the test.
9. To carry on checking the operation of Regi Clutch, do not press the Back button. Use the [ ] or
[ ] button to display [071-010].
093 008 Cyan Toner Dispense Motor (Normal)
093 009 Cyan Toner Dispense Motor (Half)
093 010 Black Toner Dispense Motor (Normal)
093 011 Black Toner Dispense Motor (Half)
Monitor Test Parameter Table
Chain Link Component
Printer Diag
Engine Diag
Engine Diag
Monitor Test
Engine Diag
Monitor Test
Monitor Test
010-001 READY
Monitor Test
041-001 READY
Monitor Test
041-001 EXEC
Monitor Test
071-002 EXEC
Monitor Test
071-002 EXEC

Xerox WorkCentre 6605 Specifications

General

Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Print Resolution	Up to 600 x 600 x 4 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Standard Paper Capacity	550 sheets
Maximum Paper Capacity	1, 250 sheets
Paper Output	250 sheets
Duplex Printing	Yes
Processor	533 MHz
Memory (Standard)	512 MB
Memory (Maximum)	1 GB
Monthly Duty Cycle	Up to 80, 000 pages
Type	Multifunction
Copy Speed	Up to 36 cpm black and color
Fax Resolution	300 x 300 dpi
Media Sizes	Letter, Legal, A4, A5, B5, Custom sizes
Connectivity	USB 2.0, Ethernet
Mobile Printing	Apple AirPrint
Operating System Compatibility	Windows, Mac, Linux
Dimensions (W x D x H)	500 mm
Weight	29.6 kg
Print Speed	Up to 36 ppm (Black) / Up to 36 ppm (Color)
