Xerox WorkCentre 6605 Service Manual

Error Troubleshooting
Xerox Internal Use Only Phaser 6600 and WorkCentre 6605
Service Manual
2-57
Relay/Signal Test
Item Range Description
Relay Test Relay Toggle Test 0150 - 9999 Toggles the Relay signal within the specified
frequency.
Relay Set Test ON, OFF Outputs the Relay signal at a specified level.
Hook Test Hook Toggle Test 0150 - 9999 Toggles the Hook signal within the specified
frequency.
Hook Set Test ON, OFF Outputs the Hook signal at a specified level.
Single Tone Send 0Hz - Continuously sends the selected frequency tone.
400Hz
462Hz
1080Hz
1100Hz
1300Hz
1500Hz
1650Hz
1850Hz
2100Hz
500Hz
600Hz
900Hz
1000Hz
DTMF Send DTMF
Continuous
0 - 9, A - D, *, # Continuously sends the DTMF signal.
DTMF
Individually
16 digits
(each digit 0 - 9,
A - D, *, #)
Sends the multiple digits DTMF signal.
Dial Pulse Send DP10
Individually
10 digits
(each digit: 0 - 9)
Sends the multiple digits dial pulse (10pps)
signal.
DP20
Individually
10 digits
(each digit: 0 - 9)
Sends the multiple digits dial pulse (20pps)
signal.
Ring Back Tone - Sends the ringback tone.
