Xerox WorkCentre 6605

Error Troubleshooting
Phaser 6600 and WorkCentre 6605 Xerox Internal Use Only
Service Manual
2-58
Data Send V.34 33600bps - Sends the data specified with speed and pattern
(no pattern for V.34).
V.34 31200bps
V.34 28800bps
V.34 26400bps
V.34 24000bps
V.34 21600bps
V.34 19200bps
V.34 31200bps
V.34 16800bps
V.34 14400bps
V.34 12000bps
V.34 9600bps
V.34 7200bps
V.34 4800bps
V.34 2400bps
V.29 7200bps 5 patterns Sends the data specified with speed and
pattern.
V.29 4800bps
V.27ter 4800bps 5 patterns Sends the data specified with speed and
pattern.
V.27ter 2400bps
V.21 300bps 5 patterns Sends the data specified with speed and
pattern.
V.17 14400bps 5 patterns Sends the data specified with speed and
pattern.
V.17 12000bps
V.17 9600bps
V.17 7200bps
Line Voltage - Checks the Line Voltage status.
Line Current
-
Checks the Line Current status.
Item Range Description
